Specifications
K65K® Technical Data
| Film format | 65mm motion picture film |
|---|
| 12-perf (1:1) | 52.5 × 52.5 mm / 1–400 fps |
|---|
| 6-perf (2:1) | 52.5 × 26.2 mm / 1–800 fps |
|---|
| Ramping | Full up/down, 24 fps sync capable |
|---|
Power & Control
| Power | 48V battery system |
|---|
| Viewfinder | Parallax viewfinder with SDI output |
|---|
| Control | Ergonomic hand unit with direct motherboard communication |
|---|
| Registration | Improved optical tracking system for maximum image stability |
|---|
Lens Mount
| Primary mount | Open-source mount (partner program) |
|---|
| Adapter | Mamiya mount (patent pending) |
|---|
Magazine
| System | TirkyMag™ (patent pending) |
|---|
| Capacity | 2000 feet |
|---|
| Features | Mid-take stop capability, acceleration/deceleration tail recovery (up to 56m saved) |
|---|
Software
| Scanner interface | Proprietary software compatible with any scanner |
|---|
Image Bandwidth Index (IBI)
In 12-perf format at 400 fps, K65K achieves an IBI of 110 Tiz — over 110 times the visual bandwidth of standard 35mm.
→ What is IBI?
